8 in 8 out DSP Audio Processor Afc Professional Camera Control Audio Processor with Ai Smart Function
- Application
- Commercial
- Hi-Fi
- Not Hi-Fi
- Activity
- Passive
- Operation Mode
- Touch Control
- Speaker Material
- Metal
- Certification
- CE, RoHS
Specifications
| Product name | 8 in 8 out DSP Audio Processor Afc Professional Camera Control Audio Processor with Ai Smart Function |
|---|---|
| Category | Speaker Amplifiers & Audio Processors |
| Customization | Available |
| Hi-Fi | Not Hi-Fi |
| Activity | Passive |
| Model NO. | DSP-880ai2/DSP-880aid2 |
| Operation Mode | Touch Control |
| Speaker Material | Metal |
| Application | Commercial |
| Certification | CE, RoHS |
| Monitor | LCD Screen |
| Signal Processing | 32bit Float Point DSP 400MHz |
| Audio System Latency | < 3ms |
| Digital-to-Analog Conversion | 24-Bit |
| Sampling Rate | 8 Balanced Inputs, Mic/Line Level |
| USB | Type-B 2.0, Driver-Free |
| TCP/IP Port | Rj-45 |
| Transport Package | Gift Box/Export Carton/Pallet |
| Specification | 483x265x44.5mm |
| Origin | Guangdong China |
| HS Code | 8518290000 |
| Production Capacity | 10000 |
| THD+N | -90dB (@17dBu, |
| A very good questions | Our advantage is more than 10 years expertise and experience in the commercial audio industry, we are good at listening to my customers, getting to know their need and proposing right solution with reliable products. With support from specialized R&D and proficient production teams, we succeed in offering innovative and sophisticated audio equipment of cutting-edge technology, and always keep in mind that to make our customers win and profitable is the core in business cooperation. |
| Price | US$338.00 1-19 Pieces US$299.00 20-49 Pieces US$246.00 50+ Pieces |
| Supplier | Guangzhou strong sound electronic equipment Co., Ltd |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Metal |
|---|
Additional data
| Model | DSP-880ai2/DSP-880aid2 |
|---|---|
| Signal Processing | 32bit float point dsp 400Mhz |
| Audio System Latency | < 3ms |
| Digital-to-Analog Conversion | 24-bit |
| Sampling Rate | 48KHz |
| Input Channels | 8 Balanced Inputs, Mic/Line Level |
| Audio Interface | 3.81 mm Phoenix Connector, 12-pin |
| Input Impedance | 16kΩ Input Impedance |
| Maximum Input Level | 17dBu (5.48Vrms) for Line /-3dBu (0.54Vrms) for Mic @ 20dB Gain Setting |
| Phantom Power | +48VDC Phantom Power, 5.5mA per Channel |
| Output Channels | 8 Balanced Outputs, Line Level |
| Output Impedance | 150Ω |
| Frequency Response | 20Hz-20kHz (±0.5dB) / Line, Input 0dBu (0.775Vrms)20Hz-20kHz (±1.5dB) / Mic, 20dB Gain Setting, Input -10dBu (0.245Vrms) |
| THD+N | THD+N: -90dB (@17dBu, 1kHz,A-weighted) / LineTHD+N: -90dB (@-6dBu, 1kHz,A-weighted) / Mic, 20dB Gain |
| SNR | 110dB(@17dBu,1kHz,A-wt)/Line100dB(@-6dBu,1kHz,A-wt)/Mic, 20dB Gain |
| USB | Type-B 2.0, Driver-Free |
| RS232 | Serial Port Communication |
| TCP/IP Port | RJ-45 |
| Power Supply | 90V-264VAC 50-60 Hz |
| Dimensions (WxDxH) | 483x265x44.5mm |
| Net Weight | 3.3Kg |
Product description
The supplier lists this product. Its stated application is Commercial. The listed model is DSP-880ai2/DSP-880aid2. The specifications below reflect the information publicly displayed on the listing. Model NO.: DSP-880ai2/DSP-880aid2. Speaker Material: Metal.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 8 in 8 out DSP Audio Processor Afc Professional Camera Control Audio?
The listed minimum order quantity is 1 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 8 in 8 out DSP Audio Processor Afc Professional Camera Control Audio cost?
The published price is US$246.00 – 338.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
DSP-880ai2/DSP-880aid2 · US$246.00 – 338.00 · MOQ 1 Pieces
