Double 10 Inch Linear Array Speaker
US$380.00 – 450.00
MOQ 20 Pieces
- Rated power
- 600W
- Impedance
- 8 ohms
- Frequency response
- 65Hz-20KHz
- Sensitivity
- 95 dB
- Application
- Commercial
- Noise
- <95dB
Specifications
| Product name | Double 10 Inch Linear Array Speaker |
|---|---|
| Category | Other Speakers & Sound Systems |
| Customization | Available |
| Noise | <95dB |
| Hi-Fi | Hi-Fi |
| Activity | Active |
| Operation Mode | Wire / Remote Control |
| Speaker System | Optional Combination |
| Speaker Material | Metal |
| Application | Commercial |
| Certification | CE |
| Monitor | VFD Screen |
| THD | <0.005% |
| Equipment Size | 275*893*478 |
| Painting Process | Environmentally Friendly Water-Based Paint |
| Mesh Protection Technology | Painted Steel Mesh |
| Transport Package | Wooden Crate Structure |
| Specification | 13.2KG |
| Origin | China |
| Production Capacity | 20000 |
| Product Description | Inverted dual 10 inch linear array speaker |
| Box material | high-density board |
| Box surface treatment | black environmentally friendly paint |
| Unit composition | High pitch 1.5 "* 1, Low pitch 10" * 2 |
| Impedance | 8 ohms |
| Sensitivity (1m/1w) | 98 dB |
| Maximum sound pressure level | 128dB |
| Rated power | 600W |
| Frequency response | 65Hz-20KHz |
| Input connection method | Four pin plug (1+/1-) |
| Coverage angle | 120 º horizontal X9 º vertical |
| Dimensions (mm) (height * width * depth) | 275 * 893 * 478 |
| Box structure | front guidance |
| TS106 frequency response | 70Hz~18KHz, number of units: LF: 1 × 6.5 "(1.5" voice coil) HF: 1 × 1 "(1.2" voice coil) Rated power: 100W Peak power: 200W Equipment weight: 5.4KG Equipment size: 330 * 210 * 225mm (height x width x depth) |
| TS108 frequency response | 65Hz~19KHz, number of units: LF: 1 × 8 "(2" voice coil) HF: 1 × 1 "(1.4" voice coil) Rated power: 200W Peak power: 400W Equipment weight: 10.8KG Equipment size: 432 * 238 * 280mm (height x width x depth) |
| TS110 frequency response | 60Hz~19KHz, number of units: LF: 1 × 10 "(2" voice coil) HF: 1 × 1 "(1.4" voice coil) Rated power: 300W Peak power: 600W Equipment weight: 16.2KG Equipment size: 508 * 305 * 350mm (height x width x depth) |
| TS112 frequency response | 55Hz~20KHz, number of units: LF: 1 × 12 "(3" voice coil) HF: 1 × 1 "(1.75" voice coil) Rated power: 400W Peak power: 800W Equipment weight: 24.6KG Equipment size: 603 * 350 * 410mm (height x width x depth) |
| TS115 frequency response | 50Hz~20KHz, number of units: LF: 1 × 15 "(3" voice coil) HF: 1 × 1 "(1.75" voice coil) Rated power: 500 W Peak power: 1000W Equipment weight: 29.6KG Equipment size: 690 * 430 * 500mm (height x width x depth) |
| Nominal impedance | 8 ohms |
| Sensitivity | 95 dB |
| Directionality | 90 ° H (horizontal) × 45 ° V (vertical) |
| Box board | high-density multi-layer composite plywood |
| Spray painting process | environmentally friendly water-based paint |
| Mesh protection process | painted steel mesh |
| Connection socket | 2 × NL4 four pin socket |
| Price | US$380.00-450.00 20 Pieces(MOQ) |
| Supplier | Changzhou Pingze Intelligent Technology Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Metal |
|---|---|
| Equipment Size | 275*893*478 |
| Box material | high-density board |
| Impedance | 8 ohms |
| Rated power | 600W |
| Nominal impedance | 8 ohms |
Product description
The supplier lists this product. Its stated application is Commercial. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Speaker Material: Metal. Box material: high-density board. Impedance: 8 ohms. Sensitivity (1m/1w): 98 dB. Rated power: 600W. Frequency response: 65Hz-20KHz. Nominal impedance: 8 ohms. Sensitivity: 95 dB.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Double 10 Inch Linear Array Speaker?
The listed minimum order quantity is 20 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Double 10 Inch Linear Array Speaker cost?
The published price is US$380.00 – 450.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
