DSP480 Professional 4×8 Digital Speaker Processor with Xmos DSP and 96kHz Audio Processing
Speaker Amplifiers & Audio Processors

DSP480 Professional 4×8 Digital Speaker Processor with Xmos DSP and 96kHz Audio Processing

Model: DSP480 Customization available Cables, Adapters & Audio Electronics
US$199.41 – 339.00
MOQ 1 set
Power
AC 220V ±10% / 50-60Hz
Application
Commercial, Home
Noise
>108 Db
Hi-Fi
Hi-Fi
Activity
Active
Operation Mode
Button Control
Send Inquiry Full specifications

Specifications

Product nameDSP480 Professional 4×8 Digital Speaker Processor with Xmos DSP and 96kHz Audio Processing
CategorySpeaker Amplifiers & Audio Processors
CustomizationAvailable
Noise>108 Db
Hi-FiHi-Fi
Model NO.DSP480
ActivityActive
Operation ModeButton Control
Speaker MaterialMetal
ApplicationCommercial, Home
CertificationCE, RoHS, CCC
MonitorLCD Screen
THD0.005%-0.01%
Processor TypeDigital Audio Matrix Processor
PC InterfacesUSB / RS485
DSP ProcessorXmos 16-Core Processor
Microphone Inputs4 XLR Inputs
Audio Outputs8 XLR Outputs
Sampling Rate96 kHz
Ad/Da Converter24-Bit
PowerAC 220V ±10% / 50-60Hz
Operating Temperature-10 °C to +60 °C
Transport PackageCarton
Specification480 × 205 × 45 mm
OriginChina
Core AdvantageDual-Ecosystem-Driven Supply Chain Matrix
Strategic Ecosystem ICore Partner in Global Smart Audio Systems
Strategic Ecosystem IIStrategic Manufacturer in Smart Interactive Display
Lightning Cloud ValueIntegrated Solution Delivery Capability
PriceUS$199.41-339.00 1 set(MOQ)
SupplierShandong Lightning Cloud Technology Engineering Co., Ltd.
Data retrieved2026-10-23

Available options

Speaker MaterialMetal
Power
AC 220V ±10%50-60Hz

Additional data

Technical Specifications
ProcessorXMOS 16-Core Processor
Sampling Rate96 kHz
Audio Resolution24-bit
ADCAKM AK5554
DACAKM AK4458
Inputs4 XLR Balanced Inputs
Outputs8 XLR Balanced Outputs
Maximum Input Level+8 dBu / 2 Vrms
Maximum Output Level+8 dBu / 2 Vrms
Input Impedance20 kΩ
Output Impedance33 Ω
THD+N< -103 dB
Signal-to-Noise Ratio112 dB (A-weighted)
Crosstalk< -100 dB
Frequency Response20 Hz – 20 kHz (±0.5 dB)
Maximum Delay1000 ms
Control InterfaceUSB / RS485
Power SupplyAC 220V ±10%, 50/60Hz
Power Consumption< 20 W
Dimensions480 × 205 × 45 mm
Weight3.5 kg

Product description

The supplier lists this product. Its stated application is Commercial, Home. The listed model is DSP480. The specifications below reflect the information publicly displayed on the listing. Noise: >108 Db. Model NO.: DSP480. Speaker Material: Metal. Power: AC 220V ±10% / 50-60Hz.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for DSP480 Professional 4×8 Digital Speaker Processor with Xmos DSP and?

The listed minimum order quantity is 1 set. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does DSP480 Professional 4×8 Digital Speaker Processor with Xmos DSP and cost?

The published price is US$199.41 – 339.00 per set. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
