Passive Noise Reduction Pilot Headsets Aviation Headset in Green
Call Center, Business & Aviation Headsets

Passive Noise Reduction Pilot Headsets Aviation Headset in Green

Model: PH-100A Customization available Headphones & Earphones
US$55.0025–49 Pieces
US$53.0050+ Pieces
MOQ 25 Pieces
Communication
Wired
Impedance
150 ohms (300 ohms each; Wired in parallel)
Frequency Response
100Hz to 8 kHz
Sensitivity
95+/-5 dB SPL (1 kHz, 1 mW input per earcup
Jack Type
Dual Plugs, 6.3mm and 5.2mm
Wire Material
PU
Send Inquiry Full specifications

Specifications

Product namePassive Noise Reduction Pilot Headsets Aviation Headset in Green
CategoryCall Center, Business & Aviation Headsets
CustomizationAvailable
Wire MaterialPU
ColorGreen
Model NO.PH-100A
CommunicationWired
UsageAviation Headset
Jack TypeDual Plugs, 6.3mm and 5.2mm
Colors8 Colors, Black, Green, Blue, Red, Pink, Yellow
Net Weight0.8kg
Gross Weight1.5kg
Warranty12 Months
PlugDual Plugs 6.3mm and 5.2mm
Transport PackageWhite Box Size: 27*20*13cm, 12PCS/CTN, 21kg/CTN
SpecificationCE, RoHS, IEC
OriginGuangdong
HS Code8529903000
Production Capacity100PCS/Day
Noise Reduction Ratings (NRR)24dB
TypeDynamic (F50)
Frequency Response100Hz to 8 kHz
Sensitivity95+/-5 dB SPL (1 kHz, 1 mW input per earcup
Impedance150 ohms (300 ohms each; Wired in parallel)
Rate Input100mW
Max. Input250mW
Element TypeNoise-canceling electret
Operating Voltage (supplied by aircraft )8-32 Volts DC
Matching Impedance150-1000 ohms
Operating Temperature-20 to 70° C
CordageRAN-1000AH Coiled cord from headset
Intercom Connections PlugU174/U
WeightsAN-1000H ----570g
Attenuation Frequency Band20Hz~20KHz
Main Attenuation Frequency Band20Hz~600Hz
Attenuation Capability18~21dB
Power Consumption30 mW
Headset size range Height10 to 14 cm
PriceUS$55.00 25-49 Pieces US$53.00 50+ Pieces
SupplierRAYTALK COMMUNICATIONS LTD
Data retrieved2026-10-23

Available options

Wire MaterialPU
ColorGreen
Colors
8 ColorsBlackGreenBlueRedPinkYellow
Impedance
150 ohms (300 ohms eachWired in parallel)
Matching Impedance150-1000 ohms
Power Consumption30 mW

Product description

The supplier lists this product. Its stated application is Aviation Headset. The listed model is PH-100A. The specifications below reflect the information publicly displayed on the listing. Wire Material: PU. Model NO.: PH-100A. Noise Reduction Ratings (NRR): 24dB. Frequency Response: 100Hz to 8 kHz. Sensitivity: 95+/-5 dB SPL (1 kHz, 1 mW input per earcup. Impedance: 150 ohms (300 ohms each; Wired in parallel). Matching Impedance: 150-1000 ohms. Attenuation Frequency Band: 20Hz~20KHz. Main Attenuation Frequency Band: 20Hz~600Hz. Power Consumption: 30 mW.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Passive Noise Reduction Pilot Headsets Aviation Headset in Green?

The listed minimum order quantity is 25 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Passive Noise Reduction Pilot Headsets Aviation Headset in Green cost?

The published price is US$53.00 – 55.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
