Square Speaker Grill Mesh Panel
Grilles, Cabinets & Enclosures

Square Speaker Grill Mesh Panel

Model: custom Customization available Speaker Parts & Accessories
US$2.50500–4,999 Pieces
US$1.805,000–49,999 Pieces
US$0.8050,000–99,999 Pieces
US$0.50100,000+ Pieces
MOQ 500 Pieces
Material
Stainless Steel
Standard
Customized Non-Standard Precision Optical Componen
Tolerance
+/-0.005mm
Surface Treatment
Polished / Brushed / Electroplated / Painted
Machining Method
Laser Cutting
Other Processing Method
CNC, Laser Cutting, Chemical Etching, Etched
Send Inquiry Full specifications

Specifications

Product nameSquare Speaker Grill Mesh Panel
CategoryGrilles, Cabinets & Enclosures
CustomizationAvailable
StandardCustomized Non-Standard Precision Optical Componen
Tolerance+/-0.005mm
Model NO.custom
Surface TreatmentPolished / Brushed / Electroplated / Painted
Machining MethodLaser Cutting
MaterialStainless Steel
Other Processing MethodCNC, Laser Cutting, Chemical Etching, Etched
Production TypeOEM Custom Manufacturing
Other Material OptionsStainless Steel , Copper, Brass, Nickel, Aluminum
Custom Hole ShapesRound, Square, Diamond, Custom
Sample Lead Time3-7 Days
Mass Production14-20 Days(Depending on Quantity)
Outer Size (Area)3-50 Mmdiameter Equivalent, or Custom (Larger Size
Thickness0.02-0.30 mm(Common: 0.05/0.08/0.10 mm)
Hole Diameter (Aperture)0.08-0.50 mm(Micro-Holes Possible by Etching)
Hole Pitch0.12-1.00 mm(Depending on Pattern & Thickness)
Dimensional Tolerance+0.01 Mmtypical (Tighter Possible by Design)
Hole Tolerance+0.01-0.03 Mmdepending on Process & Thickness
Flatness<0.05 mm Typical (Depends on Size/Thickness)
Transport PackageAnti-Static Bag + Foam Protection + Export Carton
SpecificationCustom
OriginShenzhen, China
HS Code7326909000
Production Capacity50000000 PCS /Year
Package Size15.00cm * 15.00cm * 2.00cm
Package Gross Weight0.250kg
Lead Time7 days (1 - 500 Pieces) 10 days (501 - 20000 Pieces) 15 days (20001 - 50000 Pieces) To be negotiated ( > 50000 Pieces)
PriceUS$2.50 500-4,999 Pieces US$1.80 5,000-49,999 Pieces US$0.80 50,000-99,999 Pieces US$0.50 100,000+ Pieces
SupplierShenzhen Xintu Precision Hardware Co., Ltd.
Data retrieved2026-10-23

Available options

MaterialStainless Steel
Other Material Options
Stainless SteelCopperBrassNickelAluminum
Custom Hole Shapes
RoundSquareDiamondCustom
Outer Size (Area)
3-50 Mmdiameter Equivalentor Custom (Larger Size
Thickness0.02-0.30 mm(Common: 0.05/0.08/0.10 mm)
Hole Diameter (Aperture)0.08-0.50 mm(Micro-Holes Possible by Etching)

Additional data

ParameterSpecification (Customizable)
Product NameSpeaker Grille / Speaker Mesh / Metal Mesh Panel
MaterialStainless Steel (304 / 316), Aluminum, Brass, Copper
Thickness0.02 – 1.5 mm
Hole TypeRound / Square / Slot / Hexagonal / Custom
Hole Size0.03 – 3.0 mm
Pitch (Center Distance)Custom
Open Area20% – 75%
Surface TreatmentNatural / Polished / Brushed / Painted / Anodized / Plating
Manufacturing ProcessChemical Etching / Stamping / Laser Cutting / CNC Machining
Tolerance±0.005 – ±0.1 mm (depending on process)
ShapeRound / Square / Rectangular / Dome / Ring / Custom
Edge ConditionBurr-free (etching) / Deburred
ApplicationAudio Devices / Automotive / Electronics / Acoustic Equipment
OEM / ODMSupported
Drawing FormatCAD / PDF / STEP / DXF
MOQSmall batch supported
Lead Time5 – 15 days (depending on complexity)

Product description

The supplier lists this product. The listed model is custom. The specifications below reflect the information publicly displayed on the listing. Model NO.: custom. Material: Stainless Steel. Other Material Options: Stainless Steel , Copper, Brass, Nickel, Aluminum.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Square Speaker Grill Mesh Panel?

The listed minimum order quantity is 500 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Square Speaker Grill Mesh Panel cost?

The published price is US$0.50 – 2.50 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
