Studio-Grade Multi-Channel Rack-Mountable 16×16 Digital Audio Processor
- Frequency Response
- 20 Hz – 20 kHz, ±0.2 dB
- Application
- Commercial, Home
- Noise
- ≥105dB
- Hi-Fi
- Hi-Fi
- Activity
- Passive
- Operation Mode
- Button Control
Specifications
| Product name | Studio-Grade Multi-Channel Rack-Mountable 16×16 Digital Audio Processor |
|---|---|
| Category | Speaker Amplifiers & Audio Processors |
| Customization | Available |
| Noise | ≥105dB |
| Hi-Fi | Hi-Fi |
| Model NO. | TS-1616S |
| Activity | Passive |
| Operation Mode | Button Control |
| Speaker System | Optional Combination |
| Speaker Material | Metal |
| Application | Commercial, Home |
| Certification | CE, RoHS |
| Monitor | LED Screen |
| THD | >0.01% |
| Analog Channels | 16 Inputs / 16 Outputs |
| Phantom Power | +48 V |
| Sampling Rate | 48 kHz |
| Operating Power Supply | DC 12 V / 2 a |
| Transport Package | Carton |
| Specification | standard |
| Origin | China |
| Package Size | 500.00cm * 300.00cm * 60.00cm |
| Package Gross Weight | 2.500kg |
| Lead Time | 7 days (1 - 1 set) To be negotiated ( > 1 set) |
| Input Gain Amplification | –24 dB to +18 dB, 6 dB/step, 7 steps total |
| Quantization Bit Depth | 24-bit |
| Frequency Response | 20 Hz – 20 kHz, ±0.2 dB |
| THD+N | ≤0.004 % @ 4 dBu |
| ADC Dynamic Range | 120 dB |
| DAC Dynamic Range | 120 dB |
| Input Impedance (balanced) | 20 kΩ |
| Output Impedance (balanced) | 100 Ω |
| Channel Isolation | 104 dB @ 1 kHz |
| CMRR | 70 dB @ 80 Hz |
| Maximum Input Level | +18 dBu |
| Maximum Output Level | +18 dBu |
| Noise Floor | –90 dBu |
| Dimensions (W×D×H) | 482 × 258 × 45 mm |
| Net Weight | 2.5 kg |
| Core Algorithms | Automatic Mixing, Automatic Gain Control (AGC), Feedback Suppression |
| Core Advantage | Dual-Ecosystem-Driven Supply Chain Matrix |
| Strategic Ecosystem I | Core Partner in Global Smart Audio Systems |
| Strategic Ecosystem II | Strategic Manufacturer in Smart Interactive Display |
| Lightning Cloud Value | Integrated Solution Delivery Capability |
| Price | US$900.00 1 set(MOQ) |
| Supplier | Shandong Lightning Cloud Technology Engineering Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Metal |
|---|---|
| Phantom Power | +48 V |
| Operating Power Supply | |
| Input Impedance (balanced) | 20 kΩ |
| Output Impedance (balanced) | 100 Ω |
Additional data
| Parameter (EN) | |
|---|---|
| 1 | Analog Channels: 16 Inputs / 16 Outputs |
| 2 | Input Gain Amplification: –24 dB to +18 dB, 6 dB/step, 7 steps total |
| 3 | Quantization Bit Depth: 24-bit |
| 4 | Sampling Rate: 48 kHz |
| 5 | Phantom Power: +48 V |
| 6 | Frequency Response: 20 Hz – 20 kHz, ±0.2 dB |
| 7 | THD+N: ≤0.004 % @ 4 dBu |
| 8 | ADC Dynamic Range: 120 dB |
| 9 | DAC Dynamic Range: 120 dB |
| 10 | Input Impedance (balanced): 20 kΩ |
| 11 | Output Impedance (balanced): 100 Ω |
| 12 | Channel Isolation: 104 dB @ 1 kHz |
| 13 | CMRR: 70 dB @ 80 Hz |
| 14 | Maximum Input Level: +18 dBu |
| 15 | Maximum Output Level: +18 dBu |
| 16 | Noise Floor: –90 dBu |
| 17 | Operating Power Supply: DC 12 V / 2 A |
| 18 | Dimensions (W×D×H): 482 × 258 × 45 mm |
| 19 | Net Weight: 2.5 kg |
| 20 | Core Algorithms: Automatic Mixing, Automatic Gain Control (AGC), Feedback Suppression |
Product description
The supplier lists this product. Its stated application is Commercial, Home. The listed model is TS-1616S. The specifications below reflect the information publicly displayed on the listing. Noise: ≥105dB. Model NO.: TS-1616S. Speaker Material: Metal. Phantom Power: +48 V. Operating Power Supply: DC 12 V / 2 a. Frequency Response: 20 Hz – 20 kHz, ±0.2 dB. Input Impedance (balanced): 20 kΩ. Output Impedance (balanced): 100 Ω. Noise Floor: –90 dBu.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Studio-Grade Multi-Channel Rack-Mountable 16×16 Digital Audio?
The listed minimum order quantity is 1 set. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Studio-Grade Multi-Channel Rack-Mountable 16×16 Digital Audio cost?
The published price is US$900.00 per set. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
