X12 4 Channels 12000 Watts PRO Audio Digital DSP Power Amplifier
- Frequency Response
- ±0.1dB, 20Hz - 34KHz
- Type
- Professional Amplifier
- Usage
- KTV, Bar, Disco
- Used For
- Professional
- Tube Type
- Transistor Amplifier
- Function
- Amplifier Combined
Specifications
| Product name | X12 4 Channels 12000 Watts PRO Audio Digital DSP Power Amplifier |
|---|---|
| Category | Speaker Amplifiers & Audio Processors |
| Customization | Available |
| Type | Professional Amplifier |
| Usage | KTV, Bar, Disco |
| Model NO. | X12 |
| Used For | Professional |
| Tube Type | Transistor Amplifier |
| Function | Amplifier Combined |
| Sound Channel | 4 |
| Output Number | 4 |
| Voltage | 90V-240V |
| Element Number | Push-Pull Amplifier |
| Conductive Mode | D |
| 8ω Stereo Power(RMS) | 4X1500W |
| 4ω Stereo Power(RMS) | 4X2800W |
| 2ω Stereo Power(RMS) | 4X2000W |
| Processor | Dfm Germany |
| Protection | Short Circuit, Open Circuit, Thermal, Overload, |
| Gross Weight | 18kg |
| Warranty | 2 Years |
| Transport Package | Export Standard Durable Carton Box |
| Specification | 483×459×88mm |
| Origin | China |
| HS Code | 8518400000 |
| Production Capacity | 2000 Pieces/Month |
| Package Size | 60.00cm * 58.00cm * 18.00cm |
| Package Gross Weight | 18.000kg |
| Lead Time | 5 days (1 - 10 Pieces) 15 days (11 - 50 Pieces) To be negotiated ( > 50 Pieces) |
| Input | 4 channel |
| Output | 4 channel |
| Dynamic range | >110dB |
| Frequency Response | ±0.1dB, 20Hz - 34KHz |
| Distortion | < 0.01%, 20Hz - 20KHz @ +10dBu balanced input |
| Signal to noise ratio | >120dB |
| DSP functions include | Input/output EQ |
| The Class D power module provides | High energy efficiency |
| The X12 supports modern system integration with | Ethernet / network control |
| The X12 DSP power amplifier is widely used in | Line array sound systems |
| The delivery time | it is 8-10 days if by air; it is 45-60 days if by sea. |
| Price | US$1,500.00 1-14 Pieces US$1,455.00 15+ Pieces |
| Supplier | Ascsonic Audio Technology Co., Ltd |
| Data retrieved | 2026-10-23 |
Available options
| Voltage | 90V-240V |
|---|---|
| 8ω Stereo Power(RMS) | 4X1500W |
| 4ω Stereo Power(RMS) | 4X2800W |
| 2ω Stereo Power(RMS) | 4X2000W |
| The Class D power module provides | High energy efficiency |
Additional data
| Model Name | X12 4 Channels 12000 Watts 2U DSP Digital Amplifier with DFM Processor |
|---|---|
| Input: | 4 channel |
| Output: | 4 channel |
| Processor: | DFM Germany |
| Dynamic range: | >110dB |
| Frequency Response: | ±0.1dB, 20Hz - 34KHz |
| Distortion: | < 0.01%, 20Hz - 20KHz @ +10dBu balanced input |
| Signal to noise ratio: | >120dB |
| Output Power | |
| 8Ω Stereo Power | 4×1500W |
| 4Ω Stereo Power | 4×2800W |
| 2Ω Stereo Power | 4×3000W |
| Input Impedance | 20KΩ Balanced / 10kΩ Unbalanced |
| Output Connectors | Speakon Connectors (NEUTRIK) |
| Power Requirement | 100-240V-50Hz |
| Protection | Short circuit, open circuit, thermal, overload, DC, super audio protection |
| Dimension | |
| Airframe | 483×459×88mm 18kg |
Product description
The supplier lists this product as Professional Amplifier. Its stated application is KTV, Bar, Disco. The listed model is X12. Supplier-stated function: Amplifier Combined. The specifications below reflect the information publicly displayed on the listing. Model NO.: X12. 8ω Stereo Power(RMS): 4X1500W. 4ω Stereo Power(RMS): 4X2800W. 2ω Stereo Power(RMS): 4X2000W. Frequency Response: ±0.1dB, 20Hz - 34KHz. Signal to noise ratio: >120dB. The Class D power module provides: High energy efficiency. The X12 DSP power amplifier is widely used in: Line array sound systems.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for X12 4 Channels 12000 Watts PRO Audio Digital DSP Power Amplifier?
The listed minimum order quantity is 1 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does X12 4 Channels 12000 Watts PRO Audio Digital DSP Power Amplifier cost?
The published price is US$1,455.00 – 1,500.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
X12 · US$1,455.00 – 1,500.00 · MOQ 1 Pieces
