1000W Class D RM1K Stereo Active Amplifier Module PC Software Control
Speaker Amplifiers & Audio Processors

1000W Class D RM1K Stereo Active Amplifier Module PC Software Control

Model: RM1K Customization available Cables, Adapters & Audio Electronics
US$160.002–19 Pieces
US$155.0020+ Pieces
MOQ 2 Pieces
Type
Professional Amplifier
Usage
Active PA Audio Speaker System
Used For
Professional
Tube Type
Transistor Amplifier
Function
Amplifier Combined
Sound Channel
1
Send Inquiry Full specifications

Specifications

Product name1000W Class D RM1K Stereo Active Amplifier Module PC Software Control
CategorySpeaker Amplifiers & Audio Processors
CustomizationAvailable
TypeProfessional Amplifier
UsageActive PA Audio Speaker System
Model NO.RM1K
Used ForProfessional
Tube TypeTransistor Amplifier
FunctionAmplifier Combined
Sound Channel1
Output Number1
Voltage110V or 220V
Element NumberPush-Pull Amplifier
Conductive ModeD
8ω Stereo Power(RMS)1000W
4ω Stereo Power(RMS)1100W
ProtectionShort Circuit DCP, Ovp, Uvp, Ocp, Otp
DSP FunctionMute, Polarity, Gain, Delay, Limiter, EQ, X-Over
DSP ControlUSB and RS-485
Net Weight1.7kg
Gross Weight2.7kg
Warranty2 Years
Transport PackageDurable Carton Box
Specification397*142*70mm
OriginChina
HS Code8518400000
Production Capacity2000 Pieces/Month
Package Size41.00cm * 40.00cm * 19.00cm
Package Gross Weight6.500kg
The delivery timeit is 8-10 days if by air; it is 45-60 days if by sea.
PriceUS$160.00 2-19 Pieces US$155.00 20+ Pieces
SupplierAscsonic Audio Technology Co., Ltd
Data retrieved2026-10-23

Available options

Voltage110V or 220V
8ω Stereo Power(RMS)1000W
4ω Stereo Power(RMS)1100W

Additional data

Ascsonic single channel Class-D DSP Plate Amplifier Module
ITEM/MODELRM450RM650RM800RM150NRM1K
8Ω Stereo Power1×450W1×650W1×800W1×150W1×1000W
4Ω Stereo Power1×500W1×700W1×850W1×200W1×1100W
Frequency Response20Hz-20KHz ±1dB
THD+N 1KHz 1W 8Ω<0.1%
Signal to Noise Ratio1KHz>100dB
ClassD
ProtectionShort, DCP, OVP, UVP, OCP, OTP
Operating Voltage110V version: 90V-135V / 220V versioin: 180V-265V90V-265V110V:90V-135V/220V:180V-265V
Input Sensitivity1V1V1V
Input Impedance20KΩ
DSP FunctionMUTE, Polarity, Gain, Delay, Limiter, EQ, X-Over (AM150N doesn't have DSP function)
DSP ControlUSB and RS-485
Dimensions(W×H×D) mm397*142*70206*115*67397*142*70
Net Weight(kg)1.7kg0.9kg2kg
Gross Weight(kg)2.7kg1.6kg3kg

Product description

The supplier lists this product as Professional Amplifier. Its stated application is Active PA Audio Speaker System. The listed model is RM1K. Supplier-stated function: Amplifier Combined. The specifications below reflect the information publicly displayed on the listing. Model NO.: RM1K. 8ω Stereo Power(RMS): 1000W. 4ω Stereo Power(RMS): 1100W.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 1000W Class D RM1K Stereo Active Amplifier Module PC Software Control?

The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 1000W Class D RM1K Stereo Active Amplifier Module PC Software Control cost?

The published price is US$155.00 – 160.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
